Rotary evaporator is one of the essential equipment for concentration, purification, separation, extraction and other experiments in modern laboratory. It is mainly used for continuous distillation of a large number of volatile solvents under the condition of decompression. It can separate and purify experimental solvents. In the experiment of polycyclic aromatic hydrocarbons (PAHs) extraction from water, the rotary evaporator can concentrate the experimental solvent quickly and effectively.
Model | R1010 |
Temperature control（℃） | RT～99 |
Control screen | LCD |
Heating power（W） | 3000 |
Power（W） | 3300 |
Pressure rate | ≤2kPa/h |
Maximum vacuum（Pa） | 399.9（≤3mmHg） |
Rotary motor power（W） | 100 |
Host speed | Digital DC stepless speed regulation |
Motor rotating control（rpm） | 0～120 |
Condenser | Vertical, main cold + sub cold, high efficiency three-return condenser |
Condensation area（㎡） | Main cold：0.42 |
Deputy cold：0.22 | |
Rotary flask | 10L，Flangetype Ø125mm |
Collection flask（L） | 5 |
Bath material | Stainless steel, SUS304 material |
Bath size（mm） | Ø350mm×220mm |
Temperature accuracy（℃） | ±1.5 |
Lifting mode | Electric lifting |
Lifting distance | 0～160 |
Lifting speed | 10mm/s |
Bath power（W） | 4000 |
Vacuum seal | Teflon + Teflon fluorinated rubber double seal |
Discharge valve (spool) | PTFE |
Evaporation speed（L/h） | Water：3.2 |
Ethanol：8.6 | |
Protection | Over current protection, ground fault protection, over temperature protection and dry burning protection |
Optimum ambient temperature（℃） | 5～35 |
Ambient relative humidity（％） | ≤65 |
Power | Single phase 110V/220V，50Hz/60Hz |
Product size（mm） | 920W×550D×1700H |
Product weight（kg） | 68 |
Packing size（mm） | 1020W×520D×1220H |
Gross weight（kg） | 120 |
