Rotary evaporator is now widely used in small and medium-sized experiments. It is a necessary instrument for laboratory distillation, concentration, crystallization, purification, separation and other experiments. The experimental sample is distilled under reduced pressure in a spherical flask, and the film is formed under the action of centrifugal force by constant speed rotation, so as to increase the evaporation area and improve the evaporation efficiency.
Model | R1050 |
Temperature control（℃） | RT～99 |
Control screen | LCD |
Heating power（W） | 6000 |
Power（W） | 6300 |
Pressure rate | ≤2kPa/h |
Maximum vacuum（Pa） | 399.9（≤3mmHg） |
Rotary motor power（W） | 250W brushless motor |
Host speed | Digital DC stepless speed regulation |
Motor rotating control（rpm） | 0～120 |
Condenser | Vertical, main cold + sub cold, high efficiency three-return condenser |
Condensation area（㎡） | Main cold：1.04 |
Deputy cold：0.22 | |
Rotary flask | 50L，Flangetype Ø125mm |
Collection flask（L） | 20 |
Bath material | Stainless steel, SUS304 material |
Bath size（mm） | Ø550mm×320mm |
Temperature accuracy（℃） | ±1.5 |
Lifting mode | Electric lifting |
Lifting distance | 0～180 |
Lifting speed | 10mm/s |
Bath power（W） | 4000 |
Vacuum seal | Teflon + Teflon fluorinated rubber double seal |
Discharge valve (spool) | PTFE |
Evaporation speed（L/h） | Water：9 |
Ethanol：24.5 | |
Protection | Over current protection, ground fault protection, over temperature protection and dry burning protection |
Optimum ambient temperature（℃） | 5～35 |
Ambient relative humidity（％） | ≤65 |
Power | Three phase 220V/380V，50Hz/60Hz |
Product size（mm） | 1320W×710D×2340H |
Product weight（kg） | 115 |
Packing size（mm） | 1350W×660D×1380H |
Gross weight（kg） | 180 |
